IZ1215S
RoHS
RoHS compliant
RoHS compliantPackage 8-SIP Module, 7 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
XP POWER - IZ1215S - CONVERTER, DC/DC, 3W, +/-15V
PDF
/
Buying Options
Total Price: USD $14.61
Unit Price: USD $14.6068
≥1 USD $14.6068
≥10 USD $13.78
≥100 USD $13
Inventory: 658
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Height 11.176mm
Technical
Min Input Voltage (DC) 9V
Max Input Voltage (DC) 18V
Current - Output 2 100mA
Nominal Output Voltage -15V
Max Output Power 3W
Current - Output 1 100mA
Voltage - Output 2 -15V
Control Features Enable, Active Low
Output Power 3W
Output Current 100mA
Trim/Adjustable Output NO
Operating Supply Voltage 12V
Max Output Current 100mA
Output Voltage 15V
Voltage - Isolation 1.6kV
Efficiency 82%
Number of Outputs 2
JESD-30 Code R-XSMA-T7
Pin Count 8/7
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 21.85mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 3W
Power Rating 3W
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 7
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Remote On/Off, SCP
Size / Dimension 0.86Lx0.36W x 0.44 H 21.9mmx9.2mmx11.1mm
Series IZ (3W)
Published 2010
Packaging Tube
Operating Temperature -40°C~100°C
Physical
Weight 4.5g
Package / Case 8-SIP Module, 7 Leads
Mounting Type Through Hole
Mount PCB, Through Hole
Supply Chain
Factory Lead Time 10 Weeks
