IW4805SA
RoHS
RoHS compliant
RoHS compliantPackage 8-SIP Module, 4 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 5V 1W
PDF
/
Buying Options
Total Price: USD $12.36
Unit Price: USD $12.3596
≥1 USD $12.3596
≥10 USD $11.66
≥100 USD $11
≥500 USD $10.37736
≥1000 USD $9.78996
≥3000 USD $9.23581
Inventory: 8310
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Width 9.2mm
Height 11.176mm
Technical
Min Input Voltage (DC) 36V
Max Input Voltage (DC) 72V
Max Output Power 1W
Current - Output 1 200mA
Output Power 1W
Trim/Adjustable Output NO
Input Voltage-Nom 48V
Voltage - Output 1 5V
Max Output Current 200mA
Output Voltage 5V
Voltage - Input (Max) 72V
Voltage - Isolation 1kV
Efficiency 68%
Number of Outputs 1
JESD-30 Code R-XSMA-T5
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 21.85mm
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 1W
Applications ITE (Commercial)
Type Isolated Module
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature SCP
Size / Dimension 0.86Lx0.36W x 0.44 H 21.9mmx9.2mmx11.1mm
Series IW (1W)
Published 2013
Packaging Tube
Operating Temperature -40°C~100°C With Derating
Physical
Package / Case 8-SIP Module, 4 Leads
Mounting Type Through Hole
Mount PCB, Through Hole
Supply Chain
Factory Lead Time 10 Weeks
