IV2409SA
RoHS
RoHS compliant
RoHS compliantPackage 7-SIP Module, 4 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 9V 1W
PDF
/
Buying Options
Total Price: USD $6.02
Unit Price: USD $6.01575
≥1 USD $6.01575
≥10 USD $5.67524
≥100 USD $5.354
≥500 USD $5.05094
≥1000 USD $4.76504
Inventory: 5002
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Height 9.906mm
Technical
Min Input Voltage (DC) 21.6V
Max Input Voltage (DC) 26.4V
Max Output Power 1W
Nominal Input Voltage 24V
Current - Output 1 112mA
Output Power 1W
Output Current 112mA
Trim/Adjustable Output NO
Input Voltage-Nom 24V
Max Output Current 112mA
Output Voltage 9V
Voltage - Input (Max) 26.4V
Voltage - Isolation 3kV
Efficiency 75%
Number of Outputs 1
JESD-30 Code R-XSMA-T4
Pin Count 4
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 19.5mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 1W
Power Rating 1W
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.77Lx0.24W x 0.39 H 19.5mmx6.0mmx10.0mm
Series IV (1W)
Published 2013
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Package / Case 7-SIP Module, 4 Leads
Mounting Type Through Hole
Mount PCB, Through Hole
Supply Chain
Factory Lead Time 10 Weeks
