IV0515SA
RoHS
RoHS compliant
RoHS compliantPackage 7-SIP Module, 4 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
XP POWER IV0515SA Isolated Board Mount DC/DC Converter, 3kV Isolation, Fixed, 1 Output, 4.5 V, 5.5 V, 1 W, 15 V
PDF
/
Buying Options
Total Price: USD $6.36
Unit Price: USD $6.36
≥1 USD $6.36
≥10 USD $6
≥100 USD $5.66038
Inventory: 2393
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Height 9.906mm
Technical
Min Input Voltage (DC) 4.5V
Max Input Voltage (DC) 5.5V
Nominal Output Voltage 15V
Max Output Power 1W
Nominal Input Voltage 5V
Current - Output 1 66mA
Output Power 1W
Output Current 66mA
Trim/Adjustable Output NO
Input Voltage-Nom 5V
Operating Supply Voltage 5V
Max Output Current 66mA
Output Voltage 15V
Voltage - Input (Max) 5.5V
Voltage - Isolation 3kV
Efficiency 76%
Number of Outputs 1
JESD-30 Code R-XSMA-T4
Pin Count 4
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 19.5mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 1W
Power Rating 1W
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.77Lx0.24W x 0.39 H 19.5mmx6.0mmx10.0mm
Series IV (1W)
Published 2009
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Package / Case 7-SIP Module, 4 Leads
Mounting Type Through Hole
Mount PCB, Through Hole
Supply Chain
Factory Lead Time 10 Weeks
