ITZ0948D12
RoHS
RoHS compliant
RoHS compliantPackage 8-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER +/-12V 9W
PDF
/
Buying Options
Total Price: USD $25.99
Unit Price: USD $25.9912
≥1 USD $25.9912
≥10 USD $24.52
≥100 USD $23.13208
Inventory: 49
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mounting Type Through Hole
Package / Case 8-SIP Module
Technical
Operating Temperature -40°C~85°C With Derating
Packaging Bulk
Series ITZ (9W)
Size / Dimension 0.86Lx0.38W x 0.44 H 21.9mmx9.6mmx11.2mm
Feature Remote On/Off, SCP
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Outputs 2
Efficiency 87%
Voltage - Isolation 1.5kV
Voltage - Input (Max) 75V
Voltage - Output 1 12V
Voltage - Input (Min) 18V
Current - Output (Max) 250mA 250mA
Output Power 9W
Control Features Enable, Active Low
Voltage - Output 2 -12V
Dimensions
Height 11.2mm
Compliance
RoHS Status ROHS3 Compliant
