ITX4824SA
RoHS
RoHS compliant
RoHS compliantPackage 8-SIP Module, 5 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
XP POWER ITX4824SAIsolated Board Mount DC/DC Converter, 2:1 Input, SIP, Fixed, SIP, 6 W, 24 V, 250 mA
PDF
/
Buying Options
Total Price: USD $19.94
Unit Price: USD $19.9439
≥1 USD $19.9439
≥10 USD $18.815
≥100 USD $17.75
≥500 USD $16.74528
≥1000 USD $15.79744
Inventory: 6386
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Width 9.2mm
Height 11.176mm
Technical
Min Input Voltage (DC) 36V
Max Input Voltage (DC) 75V
Nominal Output Voltage 24V
Max Output Power 6W
Current - Output 1 250mA
Output Power 6W
Trim/Adjustable Output NO
Input Voltage-Nom 48V
Voltage - Output 1 24V
Max Output Current 250mA
Output Voltage 24V
Voltage - Input (Max) 75V
Voltage - Isolation 1.5kV
Efficiency 84%
Number of Outputs 1
JESD-30 Code R-PSMA-P5
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 21.85mm
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 6W
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature SCP
Size / Dimension 0.86Lx0.36W x 0.44 H 21.9mmx9.2mmx11.2mm
Series ITX (6W)
Published 2014
Packaging Tube
Operating Temperature -40°C~65°C
Physical
Package / Case 8-SIP Module, 5 Leads
Mounting Type Through Hole
Mount PCB, Through Hole
Supply Chain
Factory Lead Time 10 Weeks
