ITX2412SA image
Favorite
ITX2412SA image
Favorite

ITX2412SA

XP Power
RoHS
RoHS RoHS compliant
Package 8-SIP Module, 5 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description XP POWER ITX2412SAIsolated Board Mount DC/DC Converter, 2:1 Input, SIP, Fixed, SIP, 6 W, 12 V, 500 mA
PDF
/
Buying Options
Total Price: USD $21.91
Unit Price: USD $21.9102
≥1 USD $21.9102
≥10 USD $20.67
≥100 USD $19.5
≥1000 USD $17.35493
Inventory: 3061
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC Unknown

Dimensions

Width 9.2mm
Height 11.176mm

Technical

Min Input Voltage (DC) 18V
Max Input Voltage (DC) 36V
Nominal Output Voltage 12V
Max Output Power 6W
Current - Output 1 500mA
Output Power 6W
Trim/Adjustable Output NO
Input Voltage-Nom 24V
Voltage - Output 1 12V
Max Output Current 500mA
Output Voltage 12V
Voltage - Input (Max) 36V
Voltage - Isolation 1.5kV
Efficiency 85%
Number of Outputs 1
JESD-30 Code R-PSMA-P5
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 21.85mm
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 6W
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature SCP
Size / Dimension 0.86Lx0.36W x 0.44 H 21.9mmx9.2mmx11.2mm
Series ITX (6W)
Published 2014
Packaging Tube
Operating Temperature -40°C~65°C

Physical

Package / Case 8-SIP Module, 5 Leads
Mounting Type Through Hole
Mount PCB, Through Hole

Supply Chain

Factory Lead Time 10 Weeks
