ITX1215S
RoHS
RoHS compliant
RoHS compliantPackage 8-SIP Module, 7 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC/DC CONVERTER, 6W, +/-15V, 0.2A
PDF
/
Buying Options
Total Price: USD $22.47
Unit Price: USD $22.472
≥1 USD $22.472
≥10 USD $21.2
≥100 USD $20
Inventory: 123
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount PCB, Through Hole
Mounting Type Through Hole
Package / Case 8-SIP Module, 7 Leads
Technical
Operating Temperature -40°C~65°C
Packaging Tube
Published 2014
Series ITX (6W)
Size / Dimension 0.86Lx0.36W x 0.44 H 21.9mmx9.2mmx11.2mm
Feature SCP
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 7
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Additional Feature -15 VOLT OUTPUT ALSO AVAILABLE
Max Power Dissipation 6W
Technology HYBRID
Terminal Position SINGLE
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Depth 21.85mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-PSMA-P7
Number of Outputs 2
Efficiency 84%
Voltage - Isolation 1.5kV
Output Voltage 15V
Max Output Current 200mA
Voltage - Output 1 15V
Input Voltage-Nom 12V
Trim/Adjustable Output NO
Current - Output (Max) 200mA 200mA
Output Power 6W
Voltage - Output 2 -15V
Current - Output 1 200mA
Max Output Power 6W
Current - Output 2 200mA
Max Input Voltage (DC) 18V
Min Input Voltage (DC) 9V
Dimensions
Height 11.176mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
