ITX0503SA

XP Power
RoHS
RoHS RoHS compliant
Package 8-SIP Module, 5 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description XP POWER ITX0503SAIsolated Board Mount DC/DC Converter, 2:1 Input, SIP, Fixed, SIP, 6 W, 3.3 V, 1.3 A
PDF
/
Buying Options
Total Price: USD $22.79
Unit Price: USD $22.79
≥1 USD $22.79
≥10 USD $21.5
Inventory: 26
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 10 Weeks

Physical

Mount PCB, Through Hole
Mounting Type Through Hole
Package / Case 8-SIP Module, 5 Leads

Technical

Operating Temperature -40°C~65°C
Packaging Tube
Published 2014
Series ITX (6W)
Size / Dimension 0.86Lx0.36W x 0.44 H 21.9mmx9.2mmx11.2mm
Feature SCP
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Max Power Dissipation 4W
Technology HYBRID
Terminal Position SINGLE
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 2.54mm
Depth 21.85mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-PSMA-P5
Number of Outputs 1
Efficiency 77%
Voltage - Isolation 1.5kV
Voltage - Input (Max) 9V
Output Voltage 3.3V
Max Output Current 1.3A
Voltage - Output 1 3.3V
Input Voltage-Nom 5V
Trim/Adjustable Output NO
Output Power 6W
Current - Output 1 1.3A
Max Output Power 6W
Nominal Output Voltage 3.3V
Max Input Voltage (DC) 9V
Min Input Voltage (DC) 4.5V

Dimensions

Height 11.176mm
Width 9.2mm

Compliance

REACH SVHC Unknown
RoHS Status ROHS3 Compliant
