ITW2415S
RoHS
RoHS compliant
RoHS compliantPackage 6-SIP Module, 5 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
XP POWER ITW2415SIsolated Board Mount DC/DC Converter, Regulated, Through Hole, 1W, 15V, 33mA, -15V, 33mA
PDF
/
Buying Options
Total Price: USD $10.79
Unit Price: USD $10.78656
≥1 USD $10.78656
≥10 USD $10.176
Inventory: 45
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Height 10.922mm
Technical
Min Input Voltage (DC) 18V
Max Input Voltage (DC) 36V
Current - Output 2 33mA
Max Output Power 1W
Current - Output 1 33mA
Voltage - Output 2 -15V
Output Power 1W
Current - Output (Max) 33mA 33mA
Trim/Adjustable Output NO
Input Voltage-Nom 24V
Voltage - Output 1 15V
Max Output Current 33mA
Output Voltage 15V
Voltage - Isolation 1.5kV
Efficiency 80%
Number of Outputs 2
JESD-30 Code R-XSMA-T5
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 17mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 1W
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature SCP
Size / Dimension 0.67Lx0.30W x 0.43 H 17.0mmx7.6mmx11.0mm
Series ITW (1W)
Published 2013
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Package / Case 6-SIP Module, 5 Leads
Mounting Type Through Hole
Mount PCB, Through Hole
Supply Chain
Factory Lead Time 10 Weeks
