ITW1212SA
RoHS
RoHS compliant
RoHS compliantPackage 6-SIP Module, 4 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
XP POWER ITW1212SAIsolated Board Mount DC/DC Converter, Regulated, SIP, Fixed, Through Hole, 1 W, 12 V, 83 mA
PDF
/
Buying Options
Total Price: USD $10.11
Unit Price: USD $10.1124
≥1 USD $10.1124
≥10 USD $9.54
≥100 USD $9
Inventory: 240
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Width 7.62mm
Height 10.922mm
Technical
Min Input Voltage (DC) 9V
Max Input Voltage (DC) 18V
Nominal Output Voltage 12V
Max Output Power 1W
Current - Output 1 83mA
Output Power 1W
Trim/Adjustable Output NO
Input Voltage-Nom 12V
Voltage - Output 1 12V
Max Output Current 83mA
Output Voltage 12V
Voltage - Input (Max) 18V
Voltage - Isolation 1.5kV
Efficiency 77%
Number of Outputs 1
JESD-30 Code R-XSMA-T5
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 17mm
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 1W
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature SCP
Size / Dimension 0.67Lx0.30W x 0.43 H 17.0mmx7.6mmx11.0mm
Series ITW (1W)
Published 2013
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Package / Case 6-SIP Module, 4 Leads
Mounting Type Through Hole
Mount PCB, Through Hole
Supply Chain
Factory Lead Time 10 Weeks
