ITQ4815SA-H
RoHS
RoHS compliant
RoHS compliantPackage 8-SIP Module, 6 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
XP POWER ITQ4815SA-H Isolated Board Mount DC/DC Converter, 3kV Isolation, Fixed, 1 Output, 18 V, 75 V, 6 W, 15 V
PDF
/
Buying Options
Total Price: USD $26.92
Unit Price: USD $26.924
≥1 USD $26.924
≥10 USD $25.4
≥100 USD $23.96226
≥1000 USD $21.32633
Inventory: 6762
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount PCB, Through Hole
Mounting Type Through Hole
Package / Case 8-SIP Module, 6 Leads
Technical
Operating Temperature -40°C~100°C
Packaging Tube
Published 2014
Series ITQ (6W)
Size / Dimension 0.86Lx0.36W x 0.44 H 21.9mmx9.2mmx11.1mm
Feature Remote On/Off, SCP
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 7
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Max Power Dissipation 6W
Technology HYBRID
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 2.54mm
Depth 21.85mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-XSMA-T7
Number of Outputs 1
Efficiency 87%
Voltage - Isolation 3kV
Voltage - Input (Max) 75V
Output Voltage 15V
Max Output Current 400mA
Voltage - Output 1 15V
Input Voltage-Nom 48V
Trim/Adjustable Output NO
Output Power 6W
Control Features Enable, Active Low
Current - Output 1 400mA
Max Output Power 6W
Max Input Voltage (DC) 75V
Min Input Voltage (DC) 18V
Dimensions
Height 11.176mm
Width 9.2mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
