ITQ4812SA
RoHS
RoHS compliant
RoHS compliantPackage 8-SIP Module, 6 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
XP POWER ITQ4812SA Isolated Board Mount DC/DC Converter, 1.5kV Isolation, Fixed, 1 Output, 18 V, 75 V, 6 W, 12 V
PDF
/
Buying Options
Total Price: USD $23.03
Unit Price: USD $23.0338
≥1 USD $23.0338
≥10 USD $21.73
≥100 USD $20.5
Inventory: 4860
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Width 9.2mm
Height 11.176mm
Technical
Min Input Voltage (DC) 18V
Max Input Voltage (DC) 75V
Max Output Power 6W
Current - Output 1 500mA
Control Features Enable, Active Low
Output Power 6W
Trim/Adjustable Output NO
Input Voltage-Nom 48V
Voltage - Output 1 12V
Max Output Current 500mA
Output Voltage 12V
Voltage - Input (Max) 75V
Voltage - Isolation 1.5kV
Efficiency 87%
Number of Outputs 1
JESD-30 Code R-XSMA-T7
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 21.85mm
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 6W
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 7
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Remote On/Off, SCP
Size / Dimension 0.86Lx0.36W x 0.44 H 21.8mmx9.2mmx11.1mm
Series ITQ (6W)
Published 2014
Packaging Tube
Operating Temperature -40°C~100°C
Physical
Package / Case 8-SIP Module, 6 Leads
Mounting Type Through Hole
Mount PCB, Through Hole
Supply Chain
Factory Lead Time 10 Weeks
