ITQ4805S
RoHS
RoHS compliant
RoHS compliantPackage 8-SIP Module, 7 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
XP POWER ITQ4805S Isolated Board Mount DC/DC Converter, Fixed, 2 Output, 18 V, 75 V, 6 W, 5 V
PDF
/
Buying Options
Total Price: USD $23.6
Unit Price: USD $23.5956
≥1 USD $23.5956
≥10 USD $22.26
≥100 USD $21
≥500 USD $19.81132
≥1000 USD $18.68993
≥3000 USD $17.632
Inventory: 3904
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount PCB, Through Hole
Mounting Type Through Hole
Package / Case 8-SIP Module, 7 Leads
Technical
Operating Temperature -40°C~100°C
Packaging Tube
Published 2013
Series ITQ (6W)
Size / Dimension 0.86Lx0.36W x 0.44 H 21.8mmx9.2mmx11.1mm
Feature Remote On/Off, SCP
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 7
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Additional Feature IT ASLO HAS -5 V OUTPUT
Max Power Dissipation 6W
Technology HYBRID
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Depth 9.2mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-XSMA-T7
Number of Outputs 2
Efficiency 82%
Voltage - Isolation 1.5kV
Output Voltage 5V
Max Output Current 600mA
Voltage - Output 1 5V
Input Voltage-Nom 48V
Trim/Adjustable Output NO
Current - Output (Max) 600mA 600mA
Output Power 6W
Control Features Enable, Active Low
Voltage - Output 2 -5V
Current - Output 1 600mA
Max Output Power 6W
Current - Output 2 600mA
Max Input Voltage (DC) 75V
Min Input Voltage (DC) 18V
Dimensions
Height 11.176mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
