ISW1205A
RoHS
RoHS compliant
RoHS compliantPackage 10-SMD Module, 6 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
XP POWER ISW1205A Isolated Board Mount DC/DC Converter, 1.5kV Isolation, Fixed, 1 Output, 11.4 V, 12.6 V, 1 W, 5 V
PDF
/
Buying Options
Total Price: USD $8.93
Unit Price: USD $8.93262
≥1 USD $8.93262
≥10 USD $8.427
≥100 USD $7.95
≥500 USD $7.5
Inventory: 116
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mount PCB, Surface Mount
Mounting Type Surface Mount
Package / Case 10-SMD Module, 6 Leads
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Published 2014
Series ISW (1W)
Size / Dimension 0.60Lx0.44W x 0.26 H 15.2mmx11.2mmx6.5mm
Feature SCP
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Isolated Module
Applications ITE (Commercial)
Max Power Dissipation 1W
Depth 15.24mm
Number of Outputs 1
Efficiency 73%
Voltage - Isolation 1.5kV
Voltage - Input (Max) 12.6V
Max Output Current 200mA
Voltage - Output 1 5V
Output Power 1W
Current - Output 1 200mA
Max Output Power 1W
Max Input Voltage (DC) 12.6V
Min Input Voltage (DC) 11.4V
Dimensions
Height 7mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
Alternative Model
