ISL4805

XP Power
RoHS
/
Package SMD/SMT
Category Power Supplies - Board Mount / DC DC Converters
Description
PDF
/
Inventory: 3277
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant
REACH SVHC Unknown

Dimensions

Width 13.7mm
Length 23.876mm
Height 7.5mm

Technical

Min Input Voltage (DC) 18V
Max Input Voltage (DC) 72V
Current - Output 2 150mA
Nominal Output Voltage -5V
Power - Output 1.5W
Max Output Power 1.5W
Current - Output 1 150mA
Max Input Voltage 72V
Min Input Voltage 18V
Voltage - Output 2 -5V
Voltage - Output 5V
Current - Output 150mA
Power Dissipation-Max 2W
Analog IC - Other Type DC-DC REGULATED POWER SUPPLY MODULE
Trim/Adjustable Output NO
Temperature Grade OTHER
Input Voltage-Nom 48V
Voltage - Output 1 5V
Max Output Current 150mA
Output Voltage 5V
Voltage - Isolation 1.5kV
Efficiency 74 %
Number of Outputs 2
JESD-30 Code R-XDMA-G6
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 23.86mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Technology HYBRID
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Number of Terminations 6
Feature SCP

Physical

Package / Case SMD/SMT
Mount PCB, Surface Mount
