ISL2403A
RoHS
RoHS compliant
RoHS compliantPackage 16-SMD Module, 6 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
XP POWER ISL2403A Isolated Board Mount DC/DC Converter, Regulated, Surface Mount DIP, Fixed, Surface Mount Device
PDF
/
Buying Options
Total Price: USD $26.5
Unit Price: USD $26.5
≥1 USD $26.5
≥10 USD $25
≥100 USD $23.58491
Inventory: 2594
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mount PCB, Surface Mount
Mounting Type Surface Mount
Package / Case 16-SMD Module, 6 Leads
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 1999
Series ISL (1.5W)
Size / Dimension 0.94Lx0.54W x 0.31 H 23.9mmx13.7mmx8.0mm
Feature SCP
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Max Power Dissipation 2W
Technology HYBRID
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 2.54mm
Depth 23.86mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-XDMA-G6
Number of Outputs 1
Efficiency 72%
Voltage - Isolation 1.5kV
Voltage - Input (Max) 36V
Output Voltage 3.3V
Max Output Current 455mA
Input Voltage-Nom 24V
Trim/Adjustable Output NO
Output Current 455mA
Output Power 1.5W
Current - Output 1 455mA
Max Output Power 1.5W
Nominal Output Voltage 3.3V
Max Input Voltage (DC) 36V
Min Input Voltage (DC) 9V
Dimensions
Height 7.874mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
