ISH0515A-H
RoHS
RoHS compliant
RoHS compliantPackage 8-SMD Module, 5 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
XP POWER ISH0515A-H Isolated Board Mount DC/DC Converter, 3kV Isolation, Fixed, 1 Output, 4.5 V, 5.5 V, 2 W, 15 V
PDF
/
Inventory: 10001
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Width 8.3mm
Height 7.366mm
Technical
Min Input Voltage (DC) 4.5V
Max Input Voltage (DC) 5.5V
Max Output Power 2W
Current - Output 1 133mA
Output Power 2W
Trim/Adjustable Output NO
Input Voltage-Nom 5V
Voltage - Output 1 15V
Max Output Current 133mA
Output Voltage 15V
Voltage - Input (Max) 5.5V
Voltage - Isolation 3kV
Efficiency 83%
Number of Outputs 1
JESD-30 Code R-XDMA-G5
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 12.7mm
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 2W
Applications ITE (Commercial)
Type Isolated Module
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature SCP
Size / Dimension 0.50Lx0.33W x 0.29 H 12.7mmx8.3mmx7.3mm
Series ISH (2W)
Published 2014
Packaging Tube
Operating Temperature -40°C~105°C
Physical
Package / Case 8-SMD Module, 5 Leads
Mounting Type Surface Mount
Mount PCB, Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
