ISF0505A

XP Power
RoHS
/
Package 8-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description XP POWER - ISF0505A - CONVERTER DC/DC, SMD PACKAGE, 1W, 5V
PDF
/
Buying Options
Total Price: USD $6.36
Unit Price: USD $6.36
≥1 USD $6.36
≥10 USD $6
≥100 USD $5.66038
≥1000 USD $5.03772
Inventory: 9056
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 10 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SMD Module

Technical

Operating Temperature -40°C~85°C
Published 2010
Series ISF (1W)
Size / Dimension 0.50Lx0.30W x 0.24 H 12.7mmx7.5mmx6.0mm
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 8
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Power Rating 1W
Technology HYBRID
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 2.54mm
Depth 12.7mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 8
JESD-30 Code R-XDMA-G8
Number of Outputs 1
Efficiency 79%
Voltage - Isolation 1kV
Voltage - Input (Max) 5.5V
Output Voltage 5V
Max Output Current 200mA
Operating Supply Voltage 5V
Voltage - Input (Min) 4.5V
Input Voltage-Nom 5V
Trim/Adjustable Output NO
Output Current 200mA
Output Power 1W
Current - Output 1 200mA
Max Output Power 1W
Nominal Output Voltage 5V
Max Input Voltage (DC) 5.5V
Min Input Voltage (DC) 4.5V

Dimensions

Height 6.25mm
Width 7.5mm

Compliance

REACH SVHC Unknown
RoHS Status RoHS Compliant
