ISF0303A

XP Power
RoHS
/
Package 8-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description XP POWER ISF0303A Isolated Board Mount DC/DC Converter, Fixed, 1 Output, 2.97 V, 3.63 V, 1 W, 3.3 V
PDF
/
Inventory: 2991
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant
REACH SVHC Unknown

Dimensions

Width 7.5mm
Height 6.25mm

Technical

Min Input Voltage (DC) 2.97V
Max Input Voltage (DC) 3.63V
Nominal Output Voltage 3.3V
Max Output Power 1W
Current - Output 1 300mA
Output Power 1W
Output Current 300mA
Trim/Adjustable Output NO
Input Voltage-Nom 3V
Voltage - Input (Min) 2.97V
Operating Supply Voltage 3.3V
Max Output Current 300mA
Output Voltage 3.3V
Voltage - Input (Max) 3.63V
Voltage - Isolation 1kV
Efficiency 73%
Number of Outputs 1
JESD-30 Code R-XDMA-G8
Pin Count 8
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 12.7mm
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Technology HYBRID
Power Rating 1W
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Size / Dimension 0.50Lx0.30W x 0.24 H 12.7mmx7.5mmx6.0mm
Series ISF (1W)
Published 2010
Operating Temperature -40°C~85°C

Physical

Package / Case 8-SMD Module
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 10 Weeks
