ISA1515-H

XP Power
RoHS
RoHS RoHS compliant
Package 10-SMD Module, 6 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description XP POWER ISA1515-H Isolated Board Mount DC/DC Converter, Fixed, 2 Output, 13.5 V, 16.5 V, 1 W, 15 V
PDF
/
Inventory: 3950
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC Unknown

Dimensions

Height 7.366mm

Technical

Min Input Voltage (DC) 13.5V
Max Input Voltage (DC) 16.5V
Current - Output 2 33mA
Max Output Power 1W
Current - Output 1 33mA
Voltage - Output 2 -15V
Output Power 1W
Current - Output (Max) 33mA 33mA
Voltage - Output 1 15V
Max Output Current 33mA
Voltage - Isolation 3kV
Efficiency 81%
Number of Outputs 2
Depth 8.3mm
Max Power Dissipation 1W
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature SCP
Size / Dimension 0.60Lx0.33W x 0.29 H 15.2mmx8.3mmx7.3mm
Series ISA (1W)
Published 2014
Packaging Tube
Operating Temperature -40°C~105°C

Physical

Package / Case 10-SMD Module, 6 Leads
Mounting Type Surface Mount
Mount PCB, Surface Mount

Supply Chain

Factory Lead Time 10 Weeks
