IQ1209S
RoHS
RoHS compliant
RoHS compliantPackage 7-SIP Module, 6 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
XP POWER IQ1209S Isolated Board Mount DC/DC Converter, Semi Regulated, Through Hole, 1W, 9V, 55.5mA, -9V, 55.5mA
PDF
/
Buying Options
Total Price: USD $6.31
Unit Price: USD $6.31238
≥1 USD $6.31238
≥10 USD $5.95508
≥100 USD $5.618
≥500 USD $5.3
≥1000 USD $5
≥3000 USD $4.71698
Inventory: 3575
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount PCB, Through Hole
Mounting Type Through Hole
Package / Case 7-SIP Module, 6 Leads
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 2008
Series IQ (1W)
Size / Dimension 0.76Lx0.24W x 0.39 H 19.3mmx6.0mmx10.0mm
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Isolated Module
Applications ITE (Commercial)
Power Rating 1W
Max Power Dissipation 1W
Depth 19.5mm
Number of Outputs 2
Efficiency 86%
Voltage - Isolation 1kV
Output Voltage 9V
Max Output Current 55.5mA
Current - Output (Max) 55.5mA 55.5mA
Output Current 55.5mA
Output Power 1W
Current - Output 1 55.5mA
Nominal Input Voltage 12V
Max Output Power 1W
Nominal Output Voltage -9V
Current - Output 2 55.5mA
Max Input Voltage (DC) 13.2V
Min Input Voltage (DC) 10.8V
Dimensions
Height 9.906mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
