IML0205S09
RoHS
RoHS compliant
RoHS compliantPackage 7-SIP Module, 4 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC-DC CONVERTER, 2W, SIP7, MEDIC
PDF
/
Buying Options
Total Price: USD $8.43
Unit Price: USD $8.427
≥1 USD $8.427
≥10 USD $7.95
≥100 USD $7.5
≥1000 USD $6.67497
Inventory: 7359
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 7-SIP Module, 4 Leads
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 2016
Series IML02 (2W)
Size / Dimension 0.77Lx0.39W x 0.47 H 19.5mmx9.8mmx12.0mm
Feature SCP
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
Type Isolated Module
Applications Medical
Max Power Dissipation 2W
Technology HYBRID
Terminal Position SINGLE
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 2.54mm
Depth 19.5mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-XSMA-P5
Number of Outputs 1
Efficiency 80%
Voltage - Isolation 4kV
Voltage - Input (Max) 5.5V
Output Voltage 9V
Max Output Current 222mA
Voltage - Output 1 9V
Input Voltage-Nom 5V
Trim/Adjustable Output NO
Output Power 2W
Current - Output 1 222mA
Max Output Power 2W
Max Input Voltage (DC) 5.5V
Min Input Voltage (DC) 4.5V
Dimensions
Height 11.938mm
Width 9.8mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
