IMA0124D03
RoHS
RoHS compliant
RoHS compliantPackage 7-SIP Module, 5 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC-DC, 1W, DUAL OUTPUT, MEDICAL
PDF
/
Buying Options
Total Price: USD $8.43
Unit Price: USD $8.427
≥1 USD $8.427
≥10 USD $7.95
≥100 USD $7.5
Inventory: 72
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 10.668mm
Technical
Voltage - Output 2 -3.3V
Output Power 1W
Current - Output (Max) 150mA 150mA
Voltage - Input (Min) 21.6V
Voltage - Output 1 3.3V
Max Output Current 150mA
Voltage - Input (Max) 26.4V
Voltage - Isolation 4kV
Efficiency 68%
Number of Outputs 2
Max Power Dissipation 1W
Applications Medical
Type Isolated Module
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature SCP
Size / Dimension 0.77Lx0.36W x 0.42 H 19.5mmx9.2mmx10.6mm
Series IMA01 (1W)
Published 2016
Packaging Tube
Operating Temperature -40°C~75°C
Physical
Package / Case 7-SIP Module, 5 Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 10 Weeks
