IMA0112D05

XP Power
RoHS
RoHS RoHS compliant
Package 7-SIP Module, 5 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description DC-DC, 1W, DUAL OUTPUT, MEDICAL
PDF
/
Buying Options
Total Price: USD $7.87
Unit Price: USD $7.8652
≥1 USD $7.8652
≥10 USD $7.42
≥100 USD $7
≥1000 USD $6.22998
Inventory: 2698
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Height 10.668mm

Technical

Voltage - Output 2 -5V
Output Power 1W
Current - Output (Max) 100mA 100mA
Voltage - Input (Min) 10.8V
Voltage - Output 1 5V
Max Output Current 100mA
Voltage - Input (Max) 13.2V
Voltage - Isolation 4kV
Efficiency 75%
Number of Outputs 2
Max Power Dissipation 1W
Applications Medical
Type Isolated Module
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature SCP
Size / Dimension 0.77Lx0.36W x 0.42 H 19.5mmx9.2mmx10.6mm
Series IMA01 (1W)
Published 2016
Packaging Tube
Operating Temperature -40°C~75°C

Physical

Package / Case 7-SIP Module, 5 Leads
Mounting Type Through Hole
Mount Through Hole

Supply Chain

Factory Lead Time 10 Weeks
