IM2415S
RoHS
RoHS compliant
RoHS compliantPackage 9-SIP Module, 7 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONVERTER, DC/DC 2W, +/-15V WIDE I/P
PDF
/
Buying Options
Total Price: USD $16.43
Unit Price: USD $16.43
≥1 USD $16.43
≥10 USD $15.5
Inventory: 32
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount PCB, Through Hole
Mounting Type Through Hole
Package / Case 9-SIP Module, 7 Leads
Technical
Operating Temperature -40°C~100°C
Packaging Tube
Published 2009
Series IM (2W)
Size / Dimension 1.02Lx0.36W x 0.49 H 26.0mmx9.2mmx12.5mm
Feature Remote On/Off, SCP
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 7
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Subcategory Other Analog ICs
Power Rating 2W
Max Power Dissipation 2W
Technology HYBRID
Terminal Position SINGLE
Number of Functions 1
Depth 26mm
JESD-30 Code R-XSMA-T7
Number of Outputs 2
Qualification Status Not Qualified
Efficiency 82%
Voltage - Isolation 1.5kV
Output Voltage 15V
Max Output Current 65mA
Operating Supply Voltage 24V
Input Voltage-Nom 24V
Trim/Adjustable Output NO
Output Current 65mA
Output Power 2W
Control Features Enable, Active Low
Voltage - Output 2 -15V
Current - Output 1 65mA
Max Output Power 2W
Nominal Output Voltage -15V
Current - Output 2 65mA
Max Input Voltage (DC) 36V
Min Input Voltage (DC) 9V
Dimensions
Height 12.446mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
