IK1215SA
RoHS
RoHS compliant
RoHS compliantPackage 4-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC/DC CONVERTER, 0.25W, ONE 15V O/P
PDF
/
Buying Options
Total Price: USD $6.36
Unit Price: USD $6.36
≥1 USD $6.36
≥10 USD $6
≥100 USD $5.66038
Inventory: 3762
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount PCB, Through Hole
Mounting Type Through Hole
Package / Case 4-SIP Module
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 2007
Series IK (0.25W)
Size / Dimension 0.46Lx0.24W x 0.50 H 11.7mmx6.0mmx12.7mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 4
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Subcategory Other Analog ICs
Power Rating 250mW
Max Power Dissipation 250mW
Technology HYBRID
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 2.54mm
Depth 11.68mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-XSMA-T4
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 67%
Voltage - Isolation 1kV
Voltage - Input (Max) 13.2V
Output Voltage 15V
Max Output Current 16.67mA
Operating Supply Voltage 12V
Input Voltage-Nom 12V
Trim/Adjustable Output NO
Output Current 16.67mA
Output Power 250mW
Current - Output 1 16.67mA
Nominal Input Voltage 12V
Max Output Power 250mW
Nominal Output Voltage 15V
Max Input Voltage (DC) 13.2V
Min Input Voltage (DC) 10.8V
Dimensions
Height 9.8mm
Width 6mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
