IK1203SA
RoHS
RoHS compliant
RoHS compliantPackage 4-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC/DC CONVERTER, 0.25W, ONE 3.3V O/P
PDF
/
Buying Options
Total Price: USD $5.62
Unit Price: USD $5.618
≥1 USD $5.618
≥10 USD $5.3
≥100 USD $5
Inventory: 5877
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Width 6mm
Height 12.7mm
Technical
Min Input Voltage (DC) 10.8V
Max Input Voltage (DC) 13.2V
Nominal Output Voltage 3.3V
Max Output Power 250mW
Nominal Input Voltage 12V
Current - Output 1 75.7mA
Output Power 250mW
Output Current 75.7mA
Trim/Adjustable Output NO
Input Voltage-Nom 12V
Operating Supply Voltage 12V
Max Output Current 75.7mA
Output Voltage 3.3V
Voltage - Input (Max) 13.2V
Voltage - Isolation 1kV
Efficiency 65%
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-XSMA-T4
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 11.68mm
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 250mW
Power Rating 250mW
Subcategory Other Analog ICs
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.46Lx0.24W x 0.50 H 11.7mmx6.0mmx12.7mm
Series IK (0.25W)
Published 2007
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Package / Case 4-SIP Module
Mounting Type Through Hole
Mount PCB, Through Hole
Supply Chain
Factory Lead Time 10 Weeks
