IK0505SA
RoHS
RoHS compliant
RoHS compliantPackage 4-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC/DC CONVERTER, 0.25W, ONE 5V O/P
PDF
/
Buying Options
Total Price: USD $5.62
Unit Price: USD $5.618
≥1 USD $5.618
≥10 USD $5.3
≥100 USD $5
≥500 USD $4.71698
≥1000 USD $4.44998
Inventory: 2697
Minimum: 1
-
+
Technical Details
Technical
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Subcategory Other Analog ICs
Power Rating 250mW
Max Power Dissipation 250mW
Technology HYBRID
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 2.54mm
Depth 11.68mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-XSMA-T4
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 66%
Voltage - Isolation 1kV
Voltage - Input (Max) 5.5V
Output Voltage 5V
Max Output Current 50mA
Operating Supply Voltage 5V
Input Voltage-Nom 5V
Trim/Adjustable Output NO
Output Current 50mA
Output Power 250mW
Current - Output 1 50mA
Nominal Input Voltage 5V
Max Output Power 250mW
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.46Lx0.24W x 0.50 H 11.7mmx6.0mmx12.7mm
Series IK (0.25W)
Published 2010
Packaging Tube
Operating Temperature -40°C~85°C
Min Input Voltage (DC) 4.5V
Max Input Voltage (DC) 5.5V
Nominal Output Voltage 5V
Physical
Package / Case 4-SIP Module
Mounting Type Through Hole
Mount PCB, Through Hole
Supply Chain
Factory Lead Time 10 Weeks
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Width 6mm
Height 12.7mm
