IH2424S
RoHS
RoHS compliant
RoHS compliantPackage 5-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER +/-24V 2W
PDF
/
Buying Options
Total Price: USD $8.76
Unit Price: USD $8.76408
≥1 USD $8.76408
≥10 USD $8.268
≥100 USD $7.8
≥500 USD $7.35849
≥1000 USD $6.94197
≥3000 USD $6.54903
Inventory: 8960
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Length 19.81mm
Height 10.16mm
Technical
Min Input Voltage (DC) 21.6V
Max Input Voltage (DC) 26.4V
Current - Output 2 42mA
Max Output Power 2W
Nominal Input Voltage 24V
Current - Output 1 42mA
Voltage - Output 2 -24V
Output Power 2W
Output Current 42mA
Current - Output (Max) 42mA 42mA
Trim/Adjustable Output NO
Input Voltage-Nom 24V
Max Output Current 42mA
Output Voltage 24V
Voltage - Isolation 1kV
Efficiency 82%
Qualification Status Not Qualified
Number of Outputs 2
JESD-30 Code R-XSMA-T5
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 19.5mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 2W
Power Rating 2W
Subcategory Other Analog ICs
Additional Feature LG-MAX, WD-MAX
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.77Lx0.28W x 0.40 H 19.5mmx7.2mmx10.2mm
Series IH (2W)
Published 2013
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Package / Case 5-SIP Module
Mounting Type Through Hole
Mount PCB, Through Hole
Supply Chain
Factory Lead Time 10 Weeks
