IH2412SH
RoHS
RoHS compliant
RoHS compliantPackage 5-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER +/-12V 2W
PDF
/
Buying Options
Total Price: USD $11.24
Unit Price: USD $11.236
≥1 USD $11.236
≥10 USD $10.6
≥100 USD $10
≥500 USD $9.43396
≥1000 USD $8.89996
Inventory: 9489
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 19.81mm
Height Seated (Max) 10.16mm
Technical
Total Power Output-Max 2W
Voltage - Output 2 -12V
Output Current 84mA
Current - Output (Max) 84mA 84mA
Trim/Adjustable Output NO
Input Voltage-Nom 24V
Voltage - Input (Min) 21.6V
Output Voltage 12V
Voltage - Input (Max) 26.4V
Voltage - Isolation 3kV
Efficiency 82%
Qualification Status Not Qualified
Number of Outputs 2
JESD-30 Code R-XSMA-T5
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology HYBRID
Power Rating 2W
Subcategory Other Analog ICs
Additional Feature LG-MAX, WD-MAX
Power (Watts) 2W
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 0.77Lx0.30W x 0.40 H 19.5mmx7.6mmx10.2mm
Series IH (2W)
Published 2009
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Surface Mount NO
Package / Case 5-SIP Module
Mounting Type Through Hole
Supply Chain
Factory Lead Time 10 Weeks
