IH1205S
RoHS
RoHS compliant
RoHS compliantPackage 5-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
XP POWER IH1205S CONVERTER, DC/DC, 2W, +/-5V
PDF
/
Buying Options
Total Price: USD $8.43
Unit Price: USD $8.427
≥1 USD $8.427
≥10 USD $7.95
≥100 USD $7.5
≥1000 USD $6.67497
Inventory: 4940
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount PCB, Through Hole
Mounting Type Through Hole
Package / Case 5-SIP Module
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 1999
Series IH (2W)
Size / Dimension 0.77Lx0.28W x 0.40 H 19.5mmx7.2mmx10.2mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Additional Feature LG-MAX, WD-MAX
Subcategory Other Analog ICs
Power Rating 2W
Max Power Dissipation 2W
Technology HYBRID
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Depth 19.5mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-XSMA-T5
Number of Outputs 2
Qualification Status Not Qualified
Efficiency 75%
Voltage - Isolation 1kV
Output Voltage 5V
Max Output Current 200mA
Operating Supply Voltage 12V
Input Voltage-Nom 12V
Trim/Adjustable Output NO
Current - Output (Max) 200mA 200mA
Output Current 200mA
Output Power 2W
Current - Output 1 200mA
Nominal Input Voltage 12V
Max Output Power 2W
Nominal Output Voltage -5V
Current - Output 2 200mA
Max Input Voltage (DC) 13.2V
Min Input Voltage (DC) 10.8V
Dimensions
Height 10.16mm
Length 19.81mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
