IEU0348D12
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP Module, 5 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC-DC CONV, 3W, 2:1 INPUT, DIP8
PDF
/
Buying Options
Total Price: USD $25.25
Unit Price: USD $25.2492
≥1 USD $25.2492
≥10 USD $23.82
≥100 USD $22.4717
Inventory: 120
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 8-DIP Module, 5 Leads
Technical
Operating Temperature -40°C~95°C
Packaging Tube
Published 2016
Series IEU03 (3W)
Size / Dimension 0.55Lx0.55W x 0.31 H 14.0mmx14.0mmx8.0mm
Feature OCP, SCP
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Isolated Module
Applications ITE (Commercial)
Max Power Dissipation 3W
Depth 14mm
Number of Outputs 2
Efficiency 85%
Voltage - Isolation 1.5kV
Max Output Current 125mA
Voltage - Output 1 12V
Current - Output (Max) 125mA 125mA
Output Power 3W
Voltage - Output 2 -12V
Current - Output 1 125mA
Max Output Power 3W
Current - Output 2 125mA
Max Input Voltage (DC) 75V
Min Input Voltage (DC) 36V
Dimensions
Height 7.874mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
