IEU0305S3V3
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP Module, 4 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC-DC CONV, 3W, 2:1 INPUT, DIP8
PDF
/
Buying Options
Total Price: USD $22.17
Unit Price: USD $22.16863
≥1 USD $22.16863
≥10 USD $20.9138
≥100 USD $19.73
Inventory: 85
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 8-DIP Module, 4 Leads
Technical
Operating Temperature -40°C~95°C
Packaging Tube
Published 2016
Series IEU03 (3W)
Size / Dimension 0.55Lx0.55W x 0.31 H 14.0mmx14.0mmx8.0mm
Feature OCP, SCP
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Isolated Module
Applications ITE (Commercial)
Max Power Dissipation 2W
Number of Outputs 1
Efficiency 79%
Voltage - Isolation 1.5kV
Voltage - Input (Max) 10V
Max Output Current 600mA
Voltage - Output 1 3.3V
Voltage - Input (Min) 4.5V
Output Power 3W
Dimensions
Height 7.874mm
Compliance
RoHS Status ROHS3 Compliant
