IEU0212D05
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP Module, 5 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC to DC Converters, 2W, DIP8 Package
PDF
/
Buying Options
Total Price: USD $21.8
Unit Price: USD $21.79784
≥1 USD $21.79784
≥10 USD $20.564
≥100 USD $19.4
≥1000 USD $17.26593
≥3000 USD $16.28861
Inventory: 6365
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Height 7.874mm
Technical
Min Input Voltage (DC) 9V
Max Input Voltage (DC) 18V
Current - Output 2 200mA
Max Output Power 2W
Current - Output 1 200mA
Voltage - Output 2 -5V
Output Power 2W
Current - Output (Max) 200mA 200mA
Voltage - Output 1 5V
Max Output Current 200mA
Voltage - Isolation 1.5kV
Efficiency 84%
Number of Outputs 2
Depth 14mm
Max Power Dissipation 2W
Applications ITE (Commercial)
Type Isolated Module
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature OCP, SCP
Size / Dimension 0.55Lx0.55W x 0.31 H 14.0mmx14.0mmx8.0mm
Series IEU02 (2W)
Published 2016
Packaging Tube
Operating Temperature -40°C~95°C With Derating
Physical
Package / Case 8-DIP Module, 5 Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 15 Weeks
