IE0512D
RoHS
RoHS compliant
RoHS compliantPackage 4-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
XP POWER - IE0512D - CONVERTER, DC/DC, 1W, 12V
PDF
/
Buying Options
Total Price: USD $5.62
Unit Price: USD $5.618
≥1 USD $5.618
≥10 USD $5.3
≥100 USD $5
Inventory: 4927
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Height 6.858mm
Technical
Min Input Voltage (DC) 4.5V
Max Input Voltage (DC) 5.5V
Nominal Output Voltage 12V
Max Output Power 1W
Current - Output 1 84mA
Output Power 1W
Output Current 84mA
Trim/Adjustable Output NO
Input Voltage-Nom 5V
Operating Supply Voltage 5V
Max Output Current 84mA
Output Voltage 12V
Voltage - Input (Max) 5.5V
Voltage - Isolation 1kV
Efficiency 78%
Number of Outputs 1
JESD-30 Code R-XDMA-T4
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 12.7mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 1W
Power Rating 1W
Additional Feature WIDTH-MAX
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.50Lx0.40W x 0.27 H 12.7mmx10.1mmx6.9mm
Series IE (1W)
Published 2009
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Package / Case 4-DIP Module
Mounting Type Through Hole
Mount PCB, Through Hole
Supply Chain
Factory Lead Time 10 Weeks
