IE0509D
RoHS
RoHS compliant
RoHS compliantPackage 4-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 9V 1W
PDF
/
Buying Options
Total Price: USD $5.28
Unit Price: USD $5.28092
≥1 USD $5.28092
≥10 USD $4.982
≥100 USD $4.7
≥500 USD $4.43396
≥1000 USD $4.18298
≥3000 USD $3.94621
Inventory: 5038
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Height 6.858mm
Technical
Min Input Voltage (DC) 4.5V
Max Input Voltage (DC) 5.5V
Max Output Power 1W
Current - Output 1 111mA
Output Power 999mW
Trim/Adjustable Output NO
Input Voltage-Nom 5V
Voltage - Output 1 9V
Max Output Current 111mA
Output Voltage 9V
Voltage - Input (Max) 5.5V
Voltage - Isolation 1kV
Efficiency 77%
Number of Outputs 1
JESD-30 Code R-XDMA-T4
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 12.7mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 1W
Additional Feature WIDTH-MAX
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.50Lx0.40W x 0.27 H 12.7mmx10.2mmx6.9mm
Series IE (1W)
Published 2013
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Package / Case 4-DIP Module
Mounting Type Through Hole
Mount PCB, Through Hole
Supply Chain
Factory Lead Time 10 Weeks
