ICH7524WS15N
RoHS
RoHS compliant
RoHS compliantPackage Half Brick
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 15V 75W
PDF
/
Inventory: 3640
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 57.9mm
Technical
Total Power Output-Max 75W
Control Features Enable, Active Low
Current - Output (Max) 5A
Trim/Adjustable Output YES
Input Voltage-Nom 24V
Voltage - Input (Min) 9V
Voltage - Output 1 15V
Output Voltage 15V
Voltage - Input (Max) 36V
Voltage - Isolation 1500V
Efficiency 84%
Number of Outputs 1
JESD-30 Code R-MDMA-P9
Pin Count 9
Number of Functions 1
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Power (Watts) 75W
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 9
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Remote On/Off, OTP, OVP, SCP, UVLO
Size / Dimension 2.40Lx2.28W x 0.50 H 61.0mmx57.9mmx12.7mm
Series ICH (200W)
Operating Temperature -40°C~100°C With Derating
Physical
Surface Mount NO
Package / Case Half Brick
Mounting Type Through Hole
