ICH7524WS15
RoHS
RoHS compliant
RoHS compliantPackage 9-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
Power Supply;DC-DC CONVERTER,75W,4:1INPUT
PDF
/
Buying Options
Total Price: USD $108
Unit Price: USD $108
≥1 USD $108
≥10 USD $101.88679
≥100 USD $96.11962
≥1000 USD $85.54612
Inventory: 4807
Minimum: 1
-
+
Technical Details
Technical
Max Output Power 75W
Max Input Voltage (DC) 36V
Min Input Voltage (DC) 9V
Current - Output 1 5A
Control Features Enable, Active High
Output Power 75W
Trim/Adjustable Output YES
Input Voltage-Nom 24V
Voltage - Output 1 15V
Max Output Current 5A
Output Voltage 15V
Voltage - Input (Max) 36V
Voltage - Isolation 1.5kV
Efficiency 84%
Number of Outputs 1
JESD-30 Code R-MDMA-P9
Pin Count 9
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 61mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 75W
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 9
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Remote On/Off, OVP, SCP
Size / Dimension 2.40Lx2.28W x 0.50 H 61.0mmx57.9mmx12.7mm
Series ICH (200W)
Published 2013
Packaging Box
Operating Temperature -40°C~100°C
Dimensions
Height 12.7mm
Width 57.9mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
Physical
Package / Case 9-DIP Module
Mounting Type Through Hole
Mount PCB, Through Hole
Supply Chain
Factory Lead Time 12 Weeks
