ICH7524WS12N
RoHS
RoHS compliant
RoHS compliantPackage Half Brick
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 12V 75W
PDF
/
Inventory: 9991
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Package / Case Half Brick
Surface Mount NO
Technical
Operating Temperature -40°C~100°C With Derating
Series ICH (200W)
Size / Dimension 2.40Lx2.28W x 0.50 H 61.0mmx57.9mmx12.7mm
Feature Remote On/Off, OTP, OVP, SCP, UVLO
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 9
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Power (Watts) 75W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Number of Functions 1
Pin Count 9
JESD-30 Code R-MDMA-P9
Number of Outputs 1
Efficiency 83%
Voltage - Isolation 1500V
Voltage - Input (Max) 36V
Output Voltage 12V
Voltage - Output 1 12V
Voltage - Input (Min) 9V
Input Voltage-Nom 24V
Trim/Adjustable Output YES
Current - Output (Max) 6.25A
Control Features Enable, Active Low
Total Power Output-Max 75W
Dimensions
Width 57.9mm
Compliance
RoHS Status ROHS3 Compliant
