ICH5012S24N

XP Power
RoHS
RoHS RoHS compliant
Package Half Brick
Category Power Supplies - Board Mount / DC DC Converters
Description DC DC CONVERTER 24V 50W
PDF
/
Inventory: 4133
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mounting Type Through Hole
Package / Case Half Brick
Surface Mount NO

Technical

Operating Temperature -40°C~100°C With Derating
Series ICH (200W)
Size / Dimension 2.40Lx2.28W x 0.50 H 61.0mmx57.9mmx12.7mm
Feature Remote On/Off, OTP, OVP, SCP, UVLO
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 9
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Power (Watts) 50W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Number of Functions 1
Pin Count 9
JESD-30 Code R-MDMA-P9
Number of Outputs 1
Efficiency 84%
Voltage - Isolation 1500V
Voltage - Input (Max) 18V
Output Voltage 24V
Voltage - Output 1 24V
Voltage - Input (Min) 9V
Input Voltage-Nom 12V
Trim/Adjustable Output YES
Current - Output (Max) 2.08A
Control Features Enable, Active Low
Total Power Output-Max 50W

Dimensions

Width 57.9mm

Compliance

RoHS Status ROHS3 Compliant
