ICH10048WS24N

XP Power
RoHS
RoHS RoHS compliant
Package Half Brick
Category Power Supplies - Board Mount / DC DC Converters
Description DC DC CONVERTER 24V 100W
PDF
/
Inventory: 7870
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Width 57.9mm

Technical

Control Features Enable, Active Low
Current - Output (Max) 4.17A
Trim/Adjustable Output YES
Input Voltage-Nom 48V
Voltage - Input (Min) 18V
Voltage - Output 1 24V
Output Voltage 24V
Voltage - Input (Max) 75V
Voltage - Isolation 1500V
Efficiency 88%
Number of Outputs 1
JESD-30 Code R-MDMA-P9
Pin Count 9
Number of Functions 1
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Power (Watts) 100W
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 9
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Remote On/Off, OTP, OVP, SCP, UVLO
Size / Dimension 2.40Lx2.28W x 0.50 H 61.0mmx57.9mmx12.7mm
Series ICH (200W)
Operating Temperature -40°C~100°C With Derating

Physical

Surface Mount NO
Package / Case Half Brick
Mounting Type Through Hole
