ICH10048WS05
RoHS
RoHS compliant
RoHS compliantPackage 9-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
Power Supply;DC-DC CONVERTER,100W,4:1 INPUT
PDF
/
Buying Options
Total Price: USD $134.83
Unit Price: USD $134.832
≥1 USD $134.832
≥10 USD $127.2
≥100 USD $120
≥500 USD $113.20755
≥1000 USD $106.79957
≥3000 USD $100.75431
Inventory: 9734
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount PCB, Through Hole
Mounting Type Through Hole
Package / Case 9-DIP Module
Technical
Operating Temperature -40°C~100°C
Packaging Box
Published 2013
Series ICH (200W)
Size / Dimension 2.40Lx2.28W x 0.50 H 61.0mmx57.9mmx12.7mm
Feature Remote On/Off, OVP, SCP
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 9
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Max Power Dissipation 100W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Depth 61mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 9
JESD-30 Code R-MDMA-P9
Number of Outputs 1
Efficiency 86%
Voltage - Isolation 1.5kV
Voltage - Input (Max) 75V
Output Voltage 5V
Max Output Current 20A
Voltage - Output 1 5V
Input Voltage-Nom 48V
Trim/Adjustable Output YES
Output Power 100W
Control Features Enable, Active High
Current - Output 1 20A
Max Output Power 100W
Max Input Voltage (DC) 75V
Min Input Voltage (DC) 18V
Dimensions
Height 12.7mm
Width 57.9mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
