ICH10048S05

XP Power
RoHS
RoHS RoHS compliant
Package 9-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description Power Supply;DC-DC CONVERTER,100W
PDF
/
Buying Options
Total Price: USD $110
Unit Price: USD $110
≥1 USD $110
≥10 USD $103.77358
≥100 USD $97.89961
≥1000 USD $87.1303
Inventory: 7083
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Mount PCB, Through Hole
Mounting Type Through Hole
Package / Case 9-DIP Module

Technical

Operating Temperature -40°C~100°C
Packaging Box
Published 2013
Series ICH (200W)
Size / Dimension 2.40Lx2.28W x 0.50 H 61.0mmx57.9mmx12.7mm
Feature Remote On/Off, OVP, SCP
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 9
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Max Power Dissipation 100W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Depth 61mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 9
JESD-30 Code R-MDMA-P9
Number of Outputs 1
Efficiency 84%
Voltage - Isolation 1.5kV
Voltage - Input (Max) 75V
Output Voltage 5V
Max Output Current 20A
Voltage - Output 1 5V
Input Voltage-Nom 48V
Trim/Adjustable Output YES
Output Power 100W
Control Features Enable, Active High
Current - Output 1 20A
Max Output Power 100W
Max Input Voltage (DC) 75V
Min Input Voltage (DC) 36V

Dimensions

Height 12.7mm
Width 57.9mm

Compliance

REACH SVHC Unknown
RoHS Status ROHS3 Compliant
