FS30-12
RoHS
RoHS compliant
RoHS compliantPackage 4-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
SINGLE O/P, DC-HV DC PCB MOUNT,
PDF
/
Buying Options
Total Price: USD $286.52
Unit Price: USD $286.518
≥1 USD $286.518
≥10 USD $270.3
≥100 USD $255
Inventory: 2711
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 26 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 4-DIP Module
Technical
Operating Temperature -25°C~75°C
Packaging Box
Published 2015
Series XP EMCO - FS (10W)
Size / Dimension 2.25Lx1.12W x 0.50 H 57.2mmx28.5mmx12.7mm
Feature Proportional Output
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type High Voltage - Isolated Module
Applications ITE (Commercial)
Max Power Dissipation 10W
Depth 57.15mm
Number of Outputs 1
Efficiency 85%
Voltage - Isolation 2.5kV
Voltage - Input (Max) 12V
Max Output Current 3.33mA
Voltage - Output 1 3000V
Voltage - Input (Min) 0.7V
Output Power 10W
Current - Output 1 3.33mA
Max Output Power 10W
Max Input Voltage (DC) 12V
Min Input Voltage (DC) 700mV
Dimensions
Height 12.7mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
