F30
RoHS
RoHS compliant
RoHS compliantPackage 5-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 3000V 10W
PDF
/
Buying Options
Total Price: USD $13.69
Unit Price: USD $13.691981
≥1 USD $13.691981
≥10 USD $12.916967
≥100 USD $12.185816
≥500 USD $11.496059
≥1000 USD $10.845333
Inventory: 1119
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 43.2mm
Height 21.6mm
Technical
Total Power Output-Max 9.9W
Control Mode VOLTAGE-MODE
Protections OUTPUT OVER CURRENT
Output Power 10W
Current - Output (Max) 3.3mA
Trim/Adjustable Output NO
Voltage - Input (Min) 0V
Voltage - Output 1 3000V
Voltage - Input (Max) 15V
Voltage - Isolation 3.5kV
Number of Outputs 1
JESD-30 Code R-MDMA-P5
Number of Functions 1
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Applications ITE (Commercial)
Type High Voltage - Isolated Module
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Proportional Output
Size / Dimension 2.80Lx1.70W x 0.85 H 71.1mmx43.2mmx21.6mm
Series XP EMCO - F (10W)
Packaging Bulk
Operating Temperature -10°C~70°C
Physical
Surface Mount NO
Package / Case 5-DIP Module
Mounting Type Through Hole
Supply Chain
Factory Lead Time 20 Weeks
