CA05N
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER -500V 1W
PDF
/
Buying Options
Total Price: USD $298.32
Unit Price: USD $298.3158
≥1 USD $298.3158
≥10 USD $281.43
≥100 USD $265.5
≥500 USD $250.4717
≥1000 USD $236.29405
Inventory: 7396
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 24 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 8-DIP Module
Technical
Operating Temperature -10°C~50°C
Packaging Box
Published 2016
Series XP EMCO - CA (1W)
Size / Dimension 1.75Lx1.10W x 0.50 H 44.5mmx27.9mmx12.7mm
Feature SCP
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 9
Type High Voltage - Non-Isolated Module
Applications ITE (Commercial)
Max Power Dissipation 1W
Technology HYBRID
Terminal Position UNSPECIFIED
Terminal Form PIN/PEG
Number of Functions 1
Depth 44.45mm
JESD-30 Code R-XXMA-P9
Min Input Voltage (DC) 11.5V
Max Input Voltage (DC) 15.5V
Max Output Power 1W
Min Output Voltage 0V
Max Output Voltage -500V
Output Power 1W
Current - Output (Max) 2mA
Trim/Adjustable Output YES
Input Voltage-Nom 12V
Max Output Current 2mA
Output Voltage -500V
Number of Outputs 1
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Height 12.7mm
