C40N
RoHS
RoHS compliant
RoHS compliantPackage 5-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER -4000V 1W
PDF
/
Buying Options
Total Price: USD $312.71
Unit Price: USD $312.712738
≥1 USD $312.712738
≥10 USD $295.012018
≥100 USD $278.313225
≥500 USD $262.559651
≥1000 USD $247.697774
Inventory: 1233
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Height 12.7mm
Technical
Min Input Voltage (DC) 11.5V
Max Input Voltage (DC) 16V
Max Output Power 1W
Min Output Voltage 0V
Max Output Voltage -4kV
Output Power 1W
Current - Output (Max) 250μA
Trim/Adjustable Output YES
Voltage - Output 1 -4000V
Max Output Current 250μA
Output Voltage 0V
Number of Outputs 1
JESD-30 Code R-XXMA-P6
Depth 44.45mm
Number of Functions 1
Terminal Form PIN/PEG
Terminal Position UNSPECIFIED
Technology HYBRID
Max Power Dissipation 1W
Applications ITE (Commercial)
Type High Voltage - Non-Isolated Module
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature SCP
Size / Dimension 1.75Lx1.11W x 0.50 H 44.5mmx28.2mmx12.7mm
Series XP EMCO - C (1W)
Packaging Box
Operating Temperature -10°C~60°C
Physical
Package / Case 5-DIP Module
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 24 Weeks
