VTM48EF060T040A00
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Power Supplies - Board Mount / DC DC Converters
Description
CONVERT DC/DC VTM 6V 40A SMD
PDF
/
Buying Options
Total Price: USD $72.95
Unit Price: USD $72.952
≥1 USD $72.952
≥10 USD $57.948
≥100 USD $52.8704
≥500 USD $51.777088
Inventory: 1077
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 22mm
Length 32.5mm
Height 6.604mm
Technical
Supply Voltage-Min (Vsup) 26V
Supply Voltage-Max (Vsup) 55V
Voltage - Input (Min) 26V
Voltage - Output 1 6V
Max Output Current 40A
Voltage - Input (Max) 55V
Voltage - Isolation 2.25kV
Efficiency 96%
Number of Outputs 1
JESD-30 Code R-XDMA-T60
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 48V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form THROUGH-HOLE
Terminal Position DUAL
Max Power Dissipation 240W
Power (Watts) 240W
Applications ITE (Commercial)
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Voltage Transformation Module
Number of Terminations 60
Moisture Sensitivity Level (MSL) 4 (72 Hours)
Part Status Active
Feature Remote On/Off, OCP, OTP, OVP, SCP
JESD-609 Code e4
Size / Dimension 1.28Lx0.87W x 0.26 H 32.5mmx22.0mmx6.7mm
Series VI Chip? VTM?
Published 2015
Packaging Tray
Operating Temperature -40°C~125°C
Physical
Package / Case Module
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
