VI-J7J-EY
RoHS
/
Package Half Brick
Category Power Supplies - Board Mount / DC DC Converters
Description
CONVERTER MOD DC/DC 36V 50W
PDF
/
Inventory: 5934
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Half Brick
Technical
Operating Temperature -10°C~100°C
Packaging Bulk
Published 2010
Series VI-J00? (50W)
Size / Dimension 2.28Lx2.40W x 0.50 H 57.9mmx70.0mmx12.7mm
JESD-609 Code e0
Feature OCP, SCP
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 9
ECCN Code EAR99
Type Isolated Module
Terminal Finish TIN LEAD OVER COPPER
Applications ITE (Commercial)
Power (Watts) 50W
Additional Feature CAN BE OPERATED AT 300V NOMINAL INPUT ALSO
Max Power Dissipation 50W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number VI-J7J
JESD-30 Code R-XDMA-P9
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 88%
Voltage - Isolation 3kV
Voltage - Input (Max) 375V
Output Voltage 36V
Max Output Current 1.39A
Voltage - Output 1 36V
Voltage - Input (Min) 100V
Input Voltage-Nom 150V
Trim/Adjustable Output YES
Dimensions
Height 12.7mm
Compliance
RoHS Status Non-RoHS Compliant
